Foundation & Anchor Requirements

The lift is only as secure as the concrete supporting it. Before installation, verify that your floor meets the minimum installation requirements.

Concrete Specifications

Minimum concrete strength: 3,000 PSI
Minimum slab thickness: 4-1/4 inches
Minimum anchor embedment: 3-1/4 inches

Important: The supplied anchors are 3/4" × 5-1/2". If more than 2-1/4 inches of the anchor extends above the finished floor after installation, the anchor does not have adequate embedment.

Anchor Installation Sequence

Anchor Installation
Figure 1 — Proper installation sequence for supplied expansion anchors.

Foundation Requirements

Maintain at least 6 inches from any slab edge or expansion joint.
Minimum anchor spacing: 6-1/2 inches.
Minimum hole depth: 4-1/4 inches.
Do not install on asphalt or unstable surfaces.
Shim columns until plumb before tightening anchors.
Torque all anchors to 130 ft-lbs.

Let's Talk

If you have questions about your concrete floor or your installation site, we'd be happy to discuss it with you.

800-667-0889

Notice

This Learning Center Document is intended as general guidance. Always follow the current installation instructions supplied with your lift. Specifications and installation requirements may change without notice.
